特征
完全符合当前行业标准
极低内阻，高分断能力
符合ROHS、HF等标准
应用
纯电动汽车
混合动力汽车
| P/N | Rated Voltage | Rated Current | Breaking Capacity | Typical Cold. Resistance (mOhms) |
Typical Voltage Drop(mV) | Typical Pre-Arcing I2t(A2Sec) |
规格书 |
| 6HVD.50 | 75VDC | 50A | 2500A@75VDC | 1.35 | 130 | 12650 | 下载 |
| 6HVD.40 | 75VDC | 40A | 2500A@75VDC | 1.65 | 119 | 8800 | 下载 |
| 6HVD.30 | 75VDC | 30A | 2500A@75VDC | 2.2 | 97 | 673 | 下载 |
| 6HVD.25 | 75VDC | 25A | 2500A@75VDC | 3.0 | 106 | 284 | 下载 |
| 6HVD.20 | 75VDC | 20A | 2500A@75VDC | 3.8 | 103 | 1256 | 下载 |
| 6HVD.15 | 75VDC | 15A | 2500A@75VDC | 5.8 | 115 | 620 | 下载 |
| 6HVD.10 | 75VDC | 10A | 2500A@75VDC | 11 | 147 | 161 | 下载 |
| 6HVD.5 | 75VDC | 5A | 2500A@75VDC | 26.5 | 174 | 28 | 下载 |
